Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 400 x 1800 mm | |
|---|---|---|
| Upper glass compartment height | 900 mm | |
| Lower solid door compartment height | 900 mm | |
| Single door width | 450 mm | |
| Upper door glass panel size | 370 x 750 mm | |
| Fixed middle partition thickness | 1.2 mm | |
| Adjustable shelf thickness | 1.0 mm | |
| Side panel thickness | 0.8 mm | |
| Handle length | 120 mm | |
| Internal shelf depth | 380 mm | |
| Base plinth height | 50 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Net weight per unit | 75 kg | |
|---|---|---|
| Uniform shelf static load capacity | 50 kg | |
| Adjustable shelf positions per compartment | 5 | |
| Recommended maximum stored items per shelf | 80 | |
| Surface corrosion resistance rating | Passes 48 hour neutral salt spray test | |
| Door hinge cycle durability | 50000 open/close cycles | |
| Lock cycle durability | 10000 lock/unlock cycles | |
| Drawer slide load/cycle durability | N/A | |
| Anti-tip pull-out resistance | 300 N | |
| Anti-tip connector requirement | 2 |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet frame and outer panels | 0.8mm thick 304 stainless steel, brushed #4 finish | |
|---|---|---|
| Upper door inserts | 5mm thick frosted tempered glass | |
| Internal adjustable shelves | 1.0mm thick 304 stainless steel, hemmed edges for safety | |
| Door handles | Brushed 304 stainless steel vertical pull handles, mounted with concealed fixings | |
| Lock mechanisms | Zinc alloy cam locks with chrome finish, keyed alike for both upper and lower compartments | |
| Door hinges | Stainless steel concealed butt hinges, 180 degree opening angle | |
| Shelf support pillars | 1.5mm thick galvanized steel slotted rails, mounted vertically on internal side panels | |
| Middle structural partition | 1.2mm thick 304 stainless steel, fully welded to cabinet frame | |
| Base plinth | 1.0mm thick 304 stainless steel, fully welded seam construction | |
| Internal corner joints | TIG welded stainless steel joints, ground and polished for smooth, easy-to-clean surfaces | |
| Back panel | 0.8mm thick 304 stainless steel, spot-welded to internal frame | |
| Anti-tip hardware | Zinc-plated steel brackets with included wall anchors |
Adjustment / rotation / tilt / mobility / storage features
| Upper compartment storage | Two hinged glass doors enclose two adjustable shelves for visible, dust-protected storage of frequently accessed supplies | |
|---|---|---|
| Lower compartment storage | Two hinged solid stainless steel doors enclose two adjustable shelves for concealed, secure storage of sensitive or less frequently used items | |
| Lockable access | Keyed cam locks secure both upper and lower door pairs, restricting access to authorized personnel only | |
| Adjustable shelf height | Shelves can be repositioned at 100mm vertical intervals along internal slotted pillars, accommodating items of varying heights from small containers to tall boxes | |
| 180 degree door opening | Concealed hinges allow doors to swing fully open parallel to cabinet sides, providing unobstructed access to full internal width without protruding handles blocking access | |
| Smooth hygienic surfaces | Brushed stainless steel finish and welded ground joints have no crevices for dirt or bacterial accumulation, compatible with standard clinical disinfection protocols | |
| Raised base design | 50mm high plinth lifts the cabinet off the floor, allowing easy cleaning underneath and preventing contact with pooled water or cleaning fluids | |
| Integrated door stops | Built-in hinge stops prevent doors from swinging too far and damaging adjacent walls or cabinet side panels during full opening | |
| Lock cylinder diameter | 20 mm | |
| Wall anchoring compatibility | Pre-punched mounting holes on back panel accommodate 2 anti-tip brackets for secure wall attachment to prevent tip-over hazards | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 | |
|---|---|---|
| Packaging carton dimensions | 980 x 480 x 1880 mm | |
| Gross shipping weight | 90 kg | |
| Packaging volume (CBM) | 0.89 cbm | |
| On-site assembly time | 20 minutes | |
| 20ft GP container loading quantity | 24 units | |
| 40ft HQ container loading quantity | 60 units | |
| Packaging protection | EPS foam corner guards, PE film wrap, corrugated cardboard outer, plywood pallet base | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Hospital clinical areas | Suitable for ward supply rooms, nurse stations and treatment rooms to store medical supplies, sterile packs and documentation, with easy-to-clean stainless steel surfaces meeting hygiene requirements | |
|---|---|---|
| Laboratory environments | Appropriate for clean labs, pharmaceutical storage areas and research facilities to store glassware, reagents and lab documents, with corrosion resistance to common cleaning agents | |
| Commercial office spaces | Can be used in general offices, admin areas and archive rooms to store files, office supplies and equipment, with lockable doors for document security | |
| Food preparation areas | Suitable for commercial kitchens and food processing facilities to store utensils, dry goods and cleaning supplies, with non-porous stainless steel surfaces meeting food contact hygiene standards | |
| Cleanroom environments | Compatible with ISO Class 8 cleanroom areas when specified with fully polished welds and no external fasteners, to minimize particle accumulation | |
| Educational facilities | Suitable for school science labs, staff rooms and administration offices to store teaching materials, lab supplies and student records, with durable construction resistant to heavy daily use |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office furniture - Storage furniture - Part 2: Safety requirements | |
|---|---|---|
| EN 16121:2013 | Non-domestic storage furniture - Requirements for safety, strength, durability and stability | |
| EN 10088-2:2014 | Stainless steels - Technical delivery conditions for sheet/plate and strip of corrosion resisting steels |
Standards applicable to China-market projects
| GB/T 13668-2015 | Steel storage cabinets for office use | |
|---|---|---|
| GB 28007-2011 | General technical requirements for furniture for children and institutional use | |
| GB/T 4897.3-2015 | Particleboard for furniture use | |
| GB/T 19001-2016 | Quality management systems requirements | |
| GB/T 3324-2017 | General technical requirements for metal furniture |
This product must meet the following technical requirements: 1. GB/T 13668-2015: Steel storage cabinets for office use; 2. GB 28007-2011: General technical requirements for furniture for children and institutional use; 3. GB/T 4897.3-2015: Particleboard for furniture use; 4. GB/T 19001-2016: Quality management systems requirements; 5. GB/T 3324-2017: General technical requirements for metal furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
