Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 400 x 1800 mm | |
|---|---|---|
| Upper door section height | 770 mm | |
| Middle drawer section height | 200 mm | |
| Lower door section height | 780 mm | |
| Individual drawer internal dimensions | 410 x 360 x 160 mm | |
| Upper cabinet internal clear height | 750 mm | |
| Lower cabinet internal clear height | 760 mm | |
| Steel body panel thickness | 0.6 mm | |
| Steel door panel thickness | 0.8 mm | |
| Handle length | 120 mm | |
| Adjustable shelf thickness | 0.7 mm | |
| Edge band (trim) thickness | 1.0 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Unit net weight range | 52 kg | |
|---|---|---|
| Uniform shelf load capacity | 40 kg | |
| Recommended maximum total load | 180 kg | |
| Key lock cycle durability | 10000 operations | |
| Drawer slide cycle durability | 50000 open/close cycles | |
| Door hinge cycle durability | 80000 open/close cycles | |
| Maximum total distributed load | 180 kg | |
| Surface scratch resistance | 2H pencil hardness | |
| Anti-tip anchor load rating | 50 kg per connector | |
| Shelf Distributed Load | 30 kg/shelf |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet body | 0.6mm thick cold-rolled steel sheet with light gray epoxy powder coating | |
|---|---|---|
| Door panels | 0.8mm thick cold-rolled steel with matching light gray powder coating | |
| Drawer panels | 0.7mm thick cold-rolled steel with matching powder coat finish | |
| Handles | Brushed nickel-plated zinc alloy recessed pull handles | |
| Locks | Brass tumbler keyed cam locks, keyed alike for upper doors, keyed alike for lower doors, individual keys for middle drawers | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Door hinges | Welded steel concealed pin hinges | |
| Internal shelves | 0.7mm thick adjustable cold-rolled steel shelves with metal support clips | |
| Surface finish | Epoxy polyester powder coating, scratch-resistant and rust-proof | |
| Main cabinet carcass | 0.6mm thick cold-rolled steel sheet with light gray epoxy powder coating, welded seam construction | |
| Back panel | 0.5mm thick cold-rolled steel sheet with matching powder coating, spot-welded to carcass rear frame | |
| Shelf support clips | Zinc-plated stamped steel support clips, 4 clips per shelf for even load distribution |
Adjustment / rotation / tilt / mobility / storage features
| Upper compartment lock | Central key lock integrated into right upper door, secures both upper doors simultaneously when locked | |
|---|---|---|
| Middle drawer locks | Individual key locks on each of the two middle drawers, allows separate secured storage for small valuables or confidential documents | |
| Lower compartment lock | Central key lock integrated into right lower door, secures both lower doors simultaneously when locked | |
| Adjustable shelving | Two adjustable shelves in upper compartment, one adjustable shelf in lower compartment, adjustable on 32mm pitch increments | |
| Drawer operation | Two middle drawers open via recessed pull handles, extend fully on ball-bearing slides to allow full access to stored contents | |
| Door operation | Double hinged doors open to 110 degrees, allowing unobstructed access to internal shelves | |
| File rail compatibility | Lower compartment supports optional FC/A4 hanging file rails for suspension folder filing | |
| Upper compartment locking | Central cam lock integrated into right upper door, engages 2-point latching to secure both upper doors simultaneously when rotated 90 degrees clockwise | |
| Middle drawer locking | Individual cam locks on each of the two middle drawers, engages drawer slide latch to prevent pull-out when locked, allowing separate secured storage for confidential items | |
| Lower compartment locking | Central cam lock integrated into right lower door, engages 2-point latching to secure both lower doors simultaneously when rotated 90 degrees clockwise | |
| Adjustable shelving configuration | 2 adjustable shelves in upper compartment, 1 adjustable shelf in lower compartment, repositionable on 32mm vertical pitch increments to accommodate variable item heights | |
| Hanging file compatibility | Lower compartment includes integrated mounting slots for optional FC/A4 hanging file rails to support suspension folder filing without additional modification |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 950 x 450 x 1850 mm | |
| Gross shipping weight | 60 kg | |
| Shipping volume per unit | 0.79 CBM | |
| Assembly time | 10 minutes | |
| 20ft GP container loading capacity | 34 units | |
| 40ft HQ container loading capacity | 84 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| General office document storage | Suitable for open plan offices, administrative departments and HR rooms to store archival files, office supplies and document folders | |
|---|---|---|
| Healthcare and laboratory storage | Suitable for clinics, clean rooms and lab environments requiring smooth, non-porous easy-to-clean steel surfaces | |
| Small business back-of-house storage | Suitable for retail stock rooms, workshop offices and small business admin areas requiring secure, durable low-maintenance storage | |
| Government and financial office use | Suitable for government offices, bank branches and accounting departments storing confidential documents, with separate locking drawers for sensitive materials | |
| School and educational facility use | Suitable for school administration offices, staff rooms and library storage areas for records and teaching materials |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable European standard for office storage furniture, specifies safety and strength requirements for storage cabinets used in non-domestic environments | |
|---|---|---|
| EN 10346:2015 | Applicable material standard for continuously hot-dip coated cold-rolled steel flat products, references substrate material quality for cabinet panels |
Standards applicable to China-market projects
| GB 18584-2001 | Applicable standards and test results require confirmation | |
|---|---|---|
| GB/T 3327-2016 | Metal furniture - General technical requirements for storage cabinets, specifies dimensional tolerance, strength and durability requirements for steel office cabinets | |
| GB/T 13668-2015 | Steel filing cabinets, specifies specific performance and construction requirements for office steel filing storage units |
This product must meet the following technical requirements: 1. GB 18584-2001: Applicable standards and test results require confirmation; 2. GB/T 3327-2016: Metal furniture - General technical requirements for storage cabinets, specifies dimensional tolerance, strength and durability requirements for steel office cabinets; 3. GB/T 13668-2015: Steel filing cabinets, specifies specific performance and construction requirements for office steel filing storage units; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
