Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 450 x 1800 mm | |
|---|---|---|
| Single compartment width | 420 mm | |
| Single upper compartment height | 860 mm | |
| Single lower compartment height | 860 mm | |
| Single compartment internal depth | 420 mm | |
| Door panel thickness | 0.8 mm | |
| Body panel thickness | 0.6 mm | |
| Vent slot dimensions per door | 120 x 40 mm | |
| Card holder size per door | 90 x 60 mm | |
| Handle protrusion from door | 20 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Product net weight | 42 kg | |
|---|---|---|
| Static load per compartment shelf | 30 kg | |
| Total cabinet static load capacity | 120 kg | |
| Maximum user count | 4 users | |
| Door hinge cycle rating | 50000 open/close cycles | |
| Lock mechanism cycle rating | 20000 lock/unlock cycles | |
| Coating salt spray resistance | 48 hours | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet main body | 0.6mm thick cold-rolled steel sheet | |
|---|---|---|
| Door panels | 0.8mm thick cold-rolled steel sheet | |
| Surface finish | Light gray epoxy-polyester powder coating | |
| Internal shelves | 0.7mm thick cold-rolled steel, fixed welded support | |
| Door hinges | 1.5mm thick stamped steel butt hinges, 2 hinges per door | |
| Locking hardware | Zinc alloy cam lock with 2 keys per compartment | |
| Door handles | Polished chrome-plated zinc alloy vertical pull handle | |
| Vent grilles | Punched louvered steel slots integrated into lower door section | |
| Label holders | Recessed clear plastic card slot integrated into upper door section | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Independent compartment access | Each of the 4 doors operates with a separate key lock, restricting access to assigned users | |
|---|---|---|
| Internal ventilation | Punched louvered vents on every door allow air exchange to prevent odor buildup inside closed compartments | |
| User identification | Recessed card holder on upper section of each door accepts standard 90mm wide name labels for user assignment | |
| Door swing | Each door opens 180 degrees outward to the side, supported by two steel butt hinges per door | |
| Freestanding installation | Full welded base frame allows placement directly on level floors without wall anchoring for standard applications | |
| Fixed shelf separation | Full width steel shelf divides each vertical column into upper and lower compartments, no adjustable shelf positions included | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 unit per carton | |
|---|---|---|
| Shipping carton dimensions | 950 x 500 x 1850 mm | |
| Gross shipping weight | 47 kg | |
| Shipping volume per unit | 0.88 CBM | |
| assembly time | 20 minutes | |
| 20ft GP container loading quantity | 32 units | |
| 40ft HQ container loading quantity | 76 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set |
Recommended spaces / users / usage modes
| Office employee storage | Suitable for office break rooms or staff areas to provide secure personal storage for bags, uniforms and personal effects for 4 employees | |
|---|---|---|
| School changing rooms | Suitable for school gym or classroom storage to hold student belongings, backpacks and sports equipment for assigned users | |
| Factory staff areas | Suitable for manufacturing facility changing rooms to store workwear and personal items for production staff | |
| Public facility storage | Suitable for gyms, swimming pools or public recreational facilities to provide temporary secure storage for visitors | |
| Small business supply storage | Suitable for retail or workshop environments to store tools, supplies or documentation with organized separated compartments |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable standard for office storage furniture safety requirements, covering stability, edge safety and strength requirements for steel storage cabinets | |
|---|---|---|
| EN 16122:2012 | Applicable standard for storage furniture strength and durability testing, specifying test methods for shelves, doors and locks |
Standards applicable to China-market projects
| GB/T 3327-2017 | Applicable standard for metal furniture general technical requirements, specifying dimensional tolerance, coating adhesion and structural stability for steel storage cabinets | |
|---|---|---|
| GB/T 13668-2015 | Applicable standard for steel storage lockers, defining compartment sizing, lock performance and load requirements for personal storage units |
This product must meet the following technical requirements: 1. GB/T 3327-2017: Applicable standard for metal furniture general technical requirements, specifying dimensional tolerance, coating adhesion and structural stability for steel storage cabinets; 2. GB/T 13668-2015: Applicable standard for steel storage lockers, defining compartment sizing, lock performance and load requirements for personal storage units; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
