Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 400 x 1800 mm | |
|---|---|---|
| Upper compartment internal height | 850 mm | |
| Lower compartment internal height | 850 mm | |
| Door panel thickness | 1.0 mm | |
| Cabinet frame wall thickness | 1.2 mm | |
| Handle length per door | 100 mm | |
| Adjustable shelf thickness | 0.8 mm | |
| Door opening clearance width per door | 420 mm | |
| Base plinth height | 50 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Net weight range | 75 kg | |
|---|---|---|
| Uniform shelf static load capacity | 50 kg per shelf | |
| Door hinge cycle rating | 50000 open/close cycles | |
| Lock mechanism durability | 10000 keyed lock cycles | |
| Maximum supported shelf positions per compartment | 4 | |
| Surface corrosion resistance rating | Suitable for 85% relative humidity environments | |
| Net unit weight | 75 kg | |
| Door hinge open/close cycle rating | 50000 cycles | |
| Cam lock keyed operation cycle rating | 10000 cycles | |
| Maximum adjustable shelf positions per compartment | 4 |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet body panels | 304 stainless steel with brushed #4 finish | |
|---|---|---|
| Door panels | 1.0mm thick stainless steel with folded reinforced edges | |
| Internal shelves | 0.8mm thick removable stainless steel | |
| Door hinges | Stainless steel lift-off detachable hinges | |
| Door handles | Stainless steel recessed pull handles | |
| Locking mechanism | Zinc alloy cam locks with two keys per compartment | |
| Internal shelf supports | Stainless steel L-shaped support brackets | |
| Door edge seals | EPDM rubber gaskets | |
| Base plinth | 1.2mm thick stainless steel folded base | |
| Cabinet carcass panels | 304 stainless steel with brushed #4 finish, fully welded seam construction | |
| Rear back panel | 0.7mm thick stainless steel sheet, spot-welded to carcass frame | |
| Internal adjustable shelves | 0.8mm thick removable stainless steel, hemmed edges for rigidity |
Adjustment / rotation / tilt / mobility / storage features
| Independent compartment locking | Separate keyed cam locks for upper and lower double-door compartments, allowing restricted access to different storage zones | |
|---|---|---|
| Adjustable shelving | Pre-punched vertical mounting slots on interior frame walls allow shelf height adjustment in 50mm increments to accommodate varying item heights | |
| Removable doors | Lift-off detachable stainless steel hinges allow full door removal for deep cleaning or oversized item loading | |
| Flush door closure | Recessed door design with full perimeter EPDM gaskets creates a tight seal preventing dust, moisture, and pest ingress into stored contents | |
| Freestanding installation | Reinforced folded base frame allows stable placement on level commercial floors without wall anchoring for standard storage loads | |
| Corrosion resistant storage | Non-porous stainless steel surface allows wipe-down cleaning with common commercial disinfectants, suitable for cleanroom, healthcare, or food service environments | |
| Dual-zone storage split | Horizontal mid-stiffener divides cabinet into two equal-height separate storage compartments to segregate stored items by use or access permission | |
| Lock mounting position height from cabinet base | 900 mm (upper lock), 450 mm (lower lock) | |
| Independent dual-compartment locking | Separate keyed cam locks for upper and lower double-door compartments, enabling restricted access to segregated storage zones | |
| Adjustable shelf positioning | Pre-punched vertical mounting slots on interior frame walls support shelf height adjustment in 50mm increments to accommodate varying stored item heights | |
| Removable door design | Lift-off detachable stainless steel hinges allow full door removal without tools for deep cleaning or loading of oversized items | |
| Sealed flush door closure | Recessed door alignment with full perimeter EPDM gaskets creates a tight seal blocking dust, moisture, and pest ingress into stored contents |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 980 x 480 x 1880 mm | |
| Gross shipping weight | 85 kg | |
| Shipping volume per unit | 0.89 CBM | |
| On-site assembly time | 15 minutes | |
| 20ft GP container loading capacity | 27 units | |
| 40ft HQ container loading capacity | 67 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| Healthcare facility storage | Suitable for hospital, clinic, or laboratory supply storage, as non-porous stainless steel surface supports frequent disinfection and resists corrosion from cleaning chemicals | |
|---|---|---|
| Commercial kitchen dry storage | Suitable for back-of-house food service storage of dry goods, utensils, or cleaning supplies, with moisture-resistant sealed doors preventing pest ingress | |
| Cleanroom and sterile environment storage | Suitable for pharmaceutical, electronic manufacturing, or lab cleanroom storage, as smooth seamless stainless steel surfaces eliminate particle traps and support regular sterilization | |
| Office archive and document storage | Suitable for general office secure storage of files, supplies, or equipment, with lockable compartments for controlled access to sensitive documents | |
| Industrial workshop storage | Suitable for manufacturing facility storage of tools, parts, or personal protective equipment, with heavy-gauge construction resisting impact and heavy load damage | |
| Janitorial and facility storage | Suitable for building maintenance storage of cleaning supplies, tools, and safety equipment, with corrosion resistant surface suitable for damp utility areas | |
| Healthcare clinical storage | Suitable for hospital, clinic, or dental facility supply storage, as non-porous stainless steel supports daily disinfection and resists corrosion from medical cleaning agents | |
| Laboratory clean storage | Suitable for pharmaceutical, biotech, or electronic cleanroom storage, as seamless stainless surfaces eliminate particle traps and support sterilization wipe-downs |
EU Market Access Requirements* EN Standards
| Office storage furniture safety standard | EN 14073:2004 | |
|---|---|---|
| Stainless steel surface finish standard | EN 10088:2014 | |
| Furniture hardware hinge performance | EN 15570:2008 | |
| Stainless steel sheet finish standard | EN 10088:2014 | |
| Furniture hardware durability standard | EN 15570:2008 |
Standards applicable to China-market projects
| Steel storage cabinet structural standard | GB/T 13668 | |
|---|---|---|
| Stainless steel sheet material standard | GB/T 3280 | |
| Furniture hardware lock performance standard | GB/T 24544 |
This product must meet the following technical requirements: 1. Steel storage cabinet structural standard: GB/T 13668; 2. Stainless steel sheet material standard: GB/T 3280; 3. Furniture hardware lock performance standard: GB/T 24544; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
