Automatic mm / inch conversion · Core engineering specifications
| Overall cabinet dimensions | 900 x 450 x 1850 mm | |
|---|---|---|
| Single compartment internal dimensions | 200 x 420 x 870 mm | |
| Door panel thickness | 0.8 mm | |
| Frame and body panel thickness | 0.6 mm | |
| Vent slot length per door | 120 mm | |
| Label holder size per door | 90 x 50 mm | |
| Base plinth height | 50 mm | |
| Door opening clearance width | 185 mm | |
| Internal shelf height per compartment | 850 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Assembled cabinet net weight | 62 kg | |
|---|---|---|
| Static load per individual compartment shelf | 30 kg | |
| Maximum recommended uniform load for entire cabinet | 240 kg | |
| Recommended maximum user count | 8 users | |
| Powder coating surface abrasion resistance | 5000 cycles | |
| Door hinge cycle rating | 50000 open/close cycles | |
| Key lock differential key combinations | 200 unique keys | |
| Static load per individual compartment base | 30 kg | |
| Maximum uniform static load for entire cabinet | 240 kg | |
| Maximum concurrent user capacity | 8 users |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet main body | 0.6mm thick cold-rolled steel sheet with light gray epoxy powder coating | |
|---|---|---|
| Locker doors | 0.8mm thick cold-rolled steel sheet with matching powder coated finish | |
| Door hinges | 1.5mm thick galvanized steel butt hinges, 3 hinges per door | |
| Lock assemblies | Zinc alloy die-cast keyed cam locks with nickel-plated finish | |
| Label holders | Recessed clear PVC card slots with steel backing frame | |
| Ventilation louvers | Integral punched steel slots on lower door section, same finish as door | |
| Internal shelves | 0.6mm thick cold-rolled steel shelf, welded or bolted to compartment sides | |
| Protective edge trim | Black PVC edge trim along all door perimeter seams | |
| Compartment bases | 0.6mm thick cold-rolled steel shelf, bolted to compartment side panels with gusseted corners for load support | |
| Assembly hardware | Grade 4.8 zinc-plated steel bolts and nuts, with plastic wall anchors for optional wall anti-tip mounting | |
| Leveling feet | Injection-molded polypropylene adjustable feet fitted to base corners, with steel threaded inserts | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Individual compartment locking | Each door secures with a separate keyed cam lock, allowing independent access for 8 separate users | |
|---|---|---|
| Ventilated air circulation | Each door includes 6 horizontal punched louvers at the lower section to reduce stale air and moisture buildup inside compartments | |
| User identification labeling | Recessed card holder at the top of every door accepts standard paper or plastic name tags without protruding hardware | |
| Integrated door pull and lock | Lock body functions as a recessed door pull to eliminate protruding handles and reduce corridor impact hazards | |
| Door swing direction | All doors open outward 180 degrees when unlocked, supported by 3 butt hinges per door to prevent sagging with repeated use | |
| Knock-down assembly design | Cabinet ships flat-packed with bolt-together construction to reduce shipping volume and allow on-site assembly | |
| Raised base design | 50mm high integrated plinth base lifts compartments off the floor to prevent water damage during floor cleaning and improve under-cabinet air flow | |
| Handle and lock assembly height from compartment bottom | 1200 mm (upper tier) / 350 mm (lower tier) | |
| Independent compartment locking | Each door secures with a separate keyed cam lock, allowing exclusive independent access for 8 separate users without master key override by default | |
| Passive compartment ventilation | Each door includes 6 horizontal punched louvers at the lower section to promote continuous air exchange, reducing stale air and moisture buildup inside closed compartments | |
| Integrated flush door pull | Lock body includes a recessed pull lip integrated into the lock housing, eliminating protruding handles and reducing impact hazards in narrow corridors | |
| Full outward door swing | All doors open outward 180 degrees when unlocked, supported by 3 butt hinges per door to provide full compartment access without blocking adjacent lockers |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 carton per fully knock-down cabinet | |
|---|---|---|
| Shipping carton dimensions | 1900 x 950 x 100 mm | |
| Gross shipping weight per unit | 67 kg | |
| Shipping volume per unit | 0.181 CBM | |
| On-site assembly time | 45 minutes per unit | |
| 20ft GP container loading quantity | 150 units | |
| 40ft HQ container loading quantity | 380 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set |
Recommended spaces / users / usage modes
| Office staff changing rooms | Suitable for medium-sized office facilities, providing 8 individual lockable compartments for employees to store personal items, bags and work apparel | |
|---|---|---|
| Educational institution dormitories and campuses | Ideal for schools, colleges and training centers to provide secure personal storage for students in hallways, gyms or dormitory common areas | |
| Industrial and factory welfare areas | Suitable for factory changing rooms, workshop break areas to store work uniforms, PPE and personal belongings, with ventilated design suitable for workwear storage | |
| Gym and fitness center changing rooms | Appropriate for fitness facilities to provide secure temporary storage for gym users, with durable powder coat finish that resists scratches from bags and equipment | |
| Public facility common areas | Usable in libraries, community centers and public service buildings for staff or visitor temporary storage, with neutral light gray finish that matches most interior color schemes | |
| Educational institution campuses | Ideal for primary/secondary schools, colleges and training centers to provide secure personal storage for students in hallway corridors, gymnasiums or dormitory common areas | |
| Industrial factory welfare areas | Suitable for manufacturing facility changing rooms and workshop break areas to store work uniforms, PPE and personal belongings, with louvered ventilation designed to reduce odor buildup from damp workwear | |
| Public service facility common areas | Usable in libraries, community centers and government service buildings for staff or visitor temporary item storage, with a neutral light gray finish that coordinates with standard institutional interior design schemes |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable European standard for office storage furniture - safety requirements, covering stability, sharp edge protection and structural strength for free-standing metal lockers | |
|---|---|---|
| EN 16121:2013 | Applicable European standard for non-domestic storage furniture - safety, strength and durability requirements for commercial and institutional lockers |
US and Canada office-furniture standards
| ANSI/BIFMA X5.3-2020 | Applicable standard for office storage units, specifying structural load, durability, stability and finish performance test methods for steel storage cabinets used in commercial spaces |
|---|
Standards applicable to China-market projects
| GB/T 3327-2023 | Applicable standard for metal office furniture - general technical requirements, specifying dimensional tolerance, coating adhesion and structural strength for steel storage cabinets | |
|---|---|---|
| GB/T 13668-2015 | Applicable standard for steel storage lockers, specifying compartment dimensions, load performance, lock security and hinge durability requirements for personnel storage units | |
| GB 18584-2001 | Applicable standard for indoor decorating and refurbishing materials - limit of harmful substances in wood furniture, applied to non-steel trim components to verify volatile emission compliance for indoor use |
This product must meet the following technical requirements: 1. GB/T 3327-2023: Applicable standard for metal office furniture - general technical requirements, specifying dimensional tolerance, coating adhesion and structural strength for steel storage cabinets; 2. GB/T 13668-2015: Applicable standard for steel storage lockers, specifying compartment dimensions, load performance, lock security and hinge durability requirements for personnel storage units; 3. GB 18584-2001: Applicable standard for indoor decorating and refurbishing materials - limit of harmful substances in wood furniture, applied to non-steel trim components to verify volatile emission compliance for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
