Automatic mm / inch conversion · Core engineering specifications
| Overall dimension | 900 x 400 x 1800 mm | |
|---|---|---|
| Per-door glass panel dimension | 390 x 1280 mm | |
| Interior adjustable shelf count | 4 pieces | |
| Per-interior-shelf usable depth | 360 mm | |
| Per-lower-drawer internal dimension | 400 x 350 x 150 mm | |
| Frame material thickness | 0.8 mm | |
| Shelf material thickness | 0.7 mm | |
| Handle length per door/drawer | 100 mm | |
| Lower drawer section height | 300 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Per adjustable shelf static load capacity | 30 kg | |
|---|---|---|
| Cabinet net weight range | 75 kg | |
| Lock cylinder durability | 10000 open/close cycles | |
| Door hinge cycle rating | 50000 open/close cycles | |
| Recommended maximum stored item height per upper tier | 300 mm | |
| Drawer slide cycle rating | 30000 open/close cycles | |
| Overall cabinet structural stability load | 150 kg total distributed interior load, no permanent deformation at rated capacity per storage furniture standards | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet body and frame | 304 grade brushed stainless steel, 0.8mm sheet thickness | |
|---|---|---|
| Upper door panels | 5mm thick frosted semi-transparent tempered glass | |
| Interior adjustable shelves | 304 grade brushed stainless steel, 0.7mm sheet thickness | |
| Door and drawer hardware | 304 stainless steel recessed pull handles, zinc alloy keyed lock cylinders | |
| Door hinges | Heavy-duty stainless steel external hinges | |
| Shelf adjustment system | Punched stainless steel side rails with 25mm increment adjustment slots | |
| Cabinet base plinth | Fully welded 304 stainless steel enclosed base | |
| Drawer construction | 0.7mm 304 stainless steel drawer bodies, with folded reinforced edges and mounted on ball-bearing slides | |
| Cabinet back panel | 0.6mm 304 stainless steel sheet, welded to rear cabinet frame for structural rigidity | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6 finish options |
Adjustment / rotation / tilt / mobility / storage features
| Upper door locking system | Central keyed lock secures both hinged glass doors simultaneously, prevents unauthorized access to upper storage | |
|---|---|---|
| Lower drawer locking system | Individual keyed locks on each of the two lower drawers, secures small high-value supplies or controlled documents | |
| Shelf height adjustment | Adjust shelves in 25mm vertical increments along perforated side rails, accommodates supplies of varying heights | |
| Door opening clearance | Hinged doors open to 180 degrees for full unobstructed access to interior shelves | |
| Drawer operation | Full-extension drawer slides allow complete pull-out access to stored items, prevents tipping under rated load | |
| Surface cleanability | Brushed stainless steel finish resists common medical disinfectant corrosion, supports daily wipe-down cleaning | |
| Installation configuration | Free-standing floor-mounted unit, requires no wall fixing for standard static load use | |
| Center door lock mounting height | 900 mm | |
| Edge safety | All exposed metal edges are deburred and polished to 1mm radius, eliminates sharp edge injury risk for clinical staff | |
| Ventilation provision | Sealed cabinet construction with no built-in ventilation slots, supports clean storage of non-sterile packaged supplies without dust ingress | |
| Lock center mounting height | 900 mm | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Packaged piece count | 1 piece | |
|---|---|---|
| Packed carton dimension | 950 x 450 x 1850 mm | |
| Packed gross weight | 85 kg | |
| Packed volume per unit | 0.79 CBM | |
| On-site assembly time | 20 minutes | |
| 20ft GP container loading quantity | 18 units | |
| 40ft HQ container loading quantity | 45 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| Hospital clinical rooms | Suitable for ward supply storage, medication organization and sterile item holding, corrosion-resistant stainless steel withstands frequent medical disinfection | |
|---|---|---|
| Dental and outpatient clinics | Stores dental instruments, disposable supplies and patient documents, lockable drawers support controlled access to sensitive items | |
| Laboratory environments | Stores glassware, lab supplies and non-corrosive reagents, smooth stainless steel surface resists chemical splashes and easy decontamination | |
| Office archive and supply rooms | Stores office files, stationery and general work supplies, adjustable shelves accommodate varying file and supply sizes | |
| Clean room and food preparation areas | Non-porous stainless steel construction meets hygienic storage requirements for controlled environment and food service spaces | |
| Hospital clinical treatment rooms | Suitable for ward supply storage, medication organization and packaged sterile item holding, corrosion-resistant stainless steel withstands multiple daily medical disinfection cycles | |
| Medical laboratory environments | Stores glassware, lab supplies and non-corrosive laboratory reagents, smooth stainless steel surface resists mild chemical splashes and supports easy decontamination | |
| Office supply and archive rooms | Stores office files, stationery and general work supplies, adjustable shelves accommodate varying file box and supply sizes |
EU Market Access Requirements* EN Standards
| Applicable EN 16121:2013 | Non-domestic storage furniture - Safety and performance requirements, applies to structural safety and load rating verification for commercial/medical use | |
|---|---|---|
| Applicable EN 14073-2:2004 | Office furniture - Storage furniture - Safety requirements, applies to stability and anti-tip performance acceptance |
Standards applicable to China-market projects
| Applicable GB/T 3324-2017 | General technical requirements for metal furniture, applies to dimensional tolerance, structural stability and surface finish acceptance of this cabinet | |
|---|---|---|
| Applicable GB/T 4893.9-2013 | Test for surface resistance to detergents and disinfectants, applies to stainless steel surface durability verification for medical cleaning regimes | |
| Applicable GB/T 10357.5-2011 | Furniture mechanical performance test for storage units, applies to shelf and drawer static load, hinge durability testing |
This product must meet the following technical requirements: 1. Applicable GB/T 3324-2017: General technical requirements for metal furniture, applies to dimensional tolerance, structural stability and surface finish acceptance of this cabinet; 2. Applicable GB/T 4893.9-2013: Test for surface resistance to detergents and disinfectants, applies to stainless steel surface durability verification for medical cleaning regimes; 3. Applicable GB/T 10357.5-2011: Furniture mechanical performance test for storage units, applies to shelf and drawer static load, hinge durability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
