Product supplier8-Door Stainless Steel Freestanding Staff Locker, 201 grade brushed stainless steel, 0.6mm sheet thickness
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 900 × 400 × 1800 mm | |
|---|---|---|
| Single compartment internal dimensions | 400 x 370 x 400 mm | |
| Door leaf thickness | 0.8 mm | |
| Cabinet body sheet thickness | 0.6 mm | |
| Door handle length | 120 mm | |
| Card holder slot size | 80 x 50 mm | |
| Ventilation grille perforation diameter | 6 mm | |
| Compartment door clearance | 5 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 55 kg | |
|---|---|---|
| Single compartment static load capacity | 30 kg | |
| Recommended number of users | 8 | |
| Door hinge cycle rating | 50000 open/close cycles | |
| Lock mechanism cycle rating | 20000 lock/unlock cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet body panels | 201 grade brushed stainless steel, 0.6mm sheet thickness | |
|---|---|---|
| Compartment doors | 201 grade brushed stainless steel, 0.8mm sheet thickness | |
| Door handles | Brushed stainless steel pull handles, polished edge finish | |
| Lock cores | Zinc alloy keyed cam locks, 2 keys per lock | |
| Door hinges | Stainless steel concealed pin hinges | |
| Label holders | Transparent ABS plastic card slots | |
| Vent perforations | Punched stainless steel round holes, 3 columns of 5 holes per door | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Compartment security | Each door is fitted with an independent keyed cam lock, supplied with 2 unique keys per compartment to secure personal belongings | |
|---|---|---|
| Ventilation | Perforated vent grilles on the lower section of every door allow continuous air circulation inside compartments to reduce moisture and odour accumulation | |
| Identification | Recessed card holder at the upper corner of each door accepts standard name tags or user number labels for easy compartment identification | |
| Construction type | Knock-down assembled structure with bolted connections between 4 horizontal stacked sections for stable freestanding placement | |
| Door operation | Side-hinged doors open 180 degrees outward to provide full access to compartment interiors without blocking adjacent lockers | |
| Interior layout | Each compartment is a single undivided open storage space with no internal shelves, sized to hold folded workwear, bags and personal items | |
| Key lock core diameter | 20 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of shipping packages | 4 | |
|---|---|---|
| Shipping carton dimensions (per package) | 920 x 420 x 470 mm | |
| Total gross shipping weight | 62 kg | |
| Total shipping volume | 0.73 CBM | |
| On-site assembly time | 40 minutes | |
| 20ft GP container loading quantity | 72 units | |
| 40ft HQ container loading quantity | 178 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Factory changing rooms | Suitable for manufacturing and processing facility staff changing areas, as stainless steel construction resists corrosion, moisture and frequent cleaning | |
|---|---|---|
| Commercial kitchen staff areas | Ideal for restaurant and catering back-of-house storage, as non-porous stainless steel surface meets food service hygiene requirements and withstands regular sanitisation | |
| Hospital and clinic staff areas | Suitable for healthcare facility personnel storage, as stainless steel material tolerates regular disinfection and prevents bacterial buildup | |
| Gym and leisure centre changing rooms | Appropriate for fitness centre changing areas, with ventilated compartments to store workout gear and separate keyed locks for user security | |
| School laboratory areas | Suitable for secondary school and university lab PPE storage, as stainless steel resists mild chemical splashes and withstands heavy student use |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable standard for office storage furniture, specifies safety and strength requirements for locking storage cabinets | |
|---|---|---|
| EN 16121:2013 | Applicable standard for non-domestic storage furniture, specifies durability, stability and safety performance requirements for high-use public/employee areas |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3327-2017 | Applicable standard for metal furniture storage cabinets, specifies dimensional tolerance, structural strength and coating performance requirements for acceptance | |
|---|---|---|
| GB/T 24821-2009 | Applicable standard for office lockers, specifies security, durability and safety requirements for personnel storage units |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3327-2017: Applicable standard for metal furniture storage cabinets, specifies dimensional tolerance, structural strength and coating performance requirements for acceptance; 2. GB/T 24821-2009: Applicable standard for office lockers, specifies security, durability and safety requirements for personnel storage units; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
