Automatic mm / inch conversion · Core engineering specifications
| Carcass Panel Thickness | 25 mm | |
|---|---|---|
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| TV console total static load capacity | 120 kg | |
|---|---|---|
| Sintered stone surface impact resistance | 6 mm steel ball drop from 300 mm no damage | |
| Set total net weight | 95 kg | |
| Recommended maximum TV size for console | 85 inches | |
| Recommended service life | 8 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop (both units) | 12mm polished gray sintered stone | |
|---|---|---|
| Frame and cabinet body | E0 grade engineered wood with walnut veneer finish | |
| Support legs | Solid rubber wood with walnut finish | |
| Drawer pulls | Brushed brass-finish zinc alloy | |
| Drawer slides | 3-section full extension ball bearing slides | |
| Back panel | 3mm thick hardboard | |
| Shelf dividers | 15mm thick engineered wood matching frame finish | |
| Surface finish on wood components | Matte PU lacquer | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| TV console storage configuration | 2 soft-close drawers + 3 divided open storage bays | |
|---|---|---|
| Coffee table storage configuration | 2 soft-close drawers + 1 divided open lower shelf | |
| Cable management for TV console | Rear pre-cut cable pass-through holes | |
| Sintered stone surface maintenance | Non-porous, wipe-clean with damp cloth | |
| Floor protection | Felt pads pre-installed on all leg bases | |
| Assembly requirement | Knock-down leg attachment, pre-assembled cabinet bodies | |
| Drawer operation | Full extension with 300mm travel | |
| Open shelf access | Front-facing open design without doors | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Primary application | Residential living rooms paired with 85inch wall-mounted TVs | |
|---|---|---|
| Secondary application | Open-plan apartment lounge areas | |
| Prohibited use case | Commercial high-traffic public spaces | |
| Flooring compatibility | Hardwood, tile, polished concrete and low-pile carpet | |
| Styling compatibility | Mid-century modern, contemporary and wabi-sabi interior schemes |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard specifications for furniture use | |
|---|---|---|
| EN 14749:2016 | Safety requirements for domestic storage furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2003 | Performance requirements for particleboard in furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 3. GB/T 4897.3-2003: Performance requirements for particleboard in furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
